CF35

Automatic
2000 cans per hour
Inbuilt pressure monitoring
Dissolved oxygen pickup < 20ppb
Servo driven seaming
Remote access module for enhanced support

The CF35 is a fully automated canning line for filling and closing aluminium standard, sleek or slim beer and beverage cans. It comprises a seven head filling gantry with pre-purge and post-fill gas injection and a single head servo motor driven seaming assembly delivering maximum positional accuracy and speed. The operator has full control over seaming and filling parameters all via the Siemens touchscreen HMI. It is manufactured fully from food grade 304 and 440C stainless steel and food grade plastic, with the most resistant grade 316 stainless steel used in contact areas. This ensures robustness and a high level of hygiene as well as the safe use of caustic and other cleaning agents. Lubrication uses a food grade grease.

Filling is fully adjustable by time; optimised by the inbuilt brite tank pressure monitor for extremely consistent filling levels. A central conveyor system with can guides provides smooth transfer of the cans, minimising sloshing and dissolved oxygen pick up. The height adjustable automated lid dispenser feeds into the seaming head, which features double row angular contact sealed for life bearings and run on the vacuum hardened cam profiles. After the seaming station, the cans are rinsed and dried.

Due to the high speed of the line we strongly recommend a depalletiser and lowerator to ensure a sufficient uninterrupted supply of cans to the machine.

Technical Data

Compressed air input: 10 mm hose push in connector / 3/8" BSP / 10 bar max./ 6 bar min / Maximal consumption of 150L min
Carbon dioxide input: 3/8" hose push in connector (John Guest) / BSP thread 3/8"
Power supply : 3-phase 400V / 50-60Hz, current consumption 16A max
Dimensions: 3000 x 1210 x 1987 mm (W x D x H)
Net weight : 550kg
